03 04
1.3 Safety Symbols
Data Hold
Auto-range
AUTO
Low Battery
Important safety information.See manual
for details.
Complies with European Union (EU) standards
Equipment protected throughout by double
insulation or reinforced insulation.
Earth ground
MEASUREMENT CATEGORY III is applicable
to test and measuring circuits connected to the
distribution part of the building's low-voltage
MAINS installation.
CAT III
Alternating Current
AC
DC Direct Current
Both direct and alternating current
Diode
Continuity Buzzer
Max Hold
M.H
D.H
1.4 Maintenance
1.4.1 Repairs should only be implemented by trained
personnel.
1.4.2 Remove test leads from measurement circuits
before opening the battery cover.
1.4.3 In order to avoid incorrect readings that may cause
damage or personal injury, replace batteries as
soon as the “ ” symbol appears.
1.4.4 Use a damp cloth and mild detergent to clean the
meter.Do not use abrasives or solvents.
1.4.5 Move the rotary switch to the OFF position when
the meter is not in use.
1.4.6 Remove the batteries if the meter is not going to
be used for an extended period of time.
2. Description
• This meter is a professional, portable meter with an
easy to read LCD screen.
• Easy to use with one hand, overload protection
provided,low battery indication, and suitable for use
in factories,schools, by enthusiasts and hobbyists alike.
• Both auto-range and manual-range available.
• Automatic power off feature
• Data hold and Max. hold features
• During use, the instrument automatically shows the
value and unit of the measurement.
Conforms to UL STD. 61010-1, 61010-2-030,
61010-2-033, 61010-031; Certified to CSA STD
C22.2 NO. 61010-1,61010-2-030, 61010-031,
IEC STD.61010-2-033
