3. Specifications
Accuracy is specified for a period of year after calibration
and at 18°C to 28°C(64°F to 82°F)with relative humidity
to 75%.
3.1 General specifications
• Environment conditions: 600V CAT III
Pollution degree: 2 Altitude < 2000m
Operating temperature: 0~40°C, 32°F~122°F
(<80% RH, <10℃ non-condensing)
Storage temperature: -10~50 °C, 14°F~122°F
(<70% RH, battery removed)
• Max. Voltage Between Terminals
And Earth Ground: 600V DC or AC
• Auto ranges and manual range.
• Display: 20mm LCD
• Max. Show Value: 1999 (3 ½)
• Polarity Indication: ‘-’indicates negative polarity.
• Overrange Indication: Display ‘OL’.
• Sampling Time: approx. 0.4 second
• Unit showing: showing of function and electrical
capacity.
• Low Battery Indication: displayed
• Fuse Protection: FF400mA 600V
• Auto power off time: 15 min.
• Power Supply: 1.5V×2 AAA .
• Dimension: 222×43×29 mm
• Weight: approx. 129g(including battery)
H
batteries
3.2 Technical Specifications
(ambient temperature: 23±5°C, relative humidity <75%)
2V
20V
200V
0.01V
0.001V
0.1V
200mV 0.1mV
Input impedance: 10MΩ
- Overload protection: 200mV range: 250V DC or AC rms
2V-600V ranges: 600V DC or AC rms
- Max. input voltage: 600V DC
±(0.7% reading + 2dgt)
Measuring Range
Resolution
Accuracy
3.2.1 DC Voltage
600V
1V
2V
20V
200V
0.01V
0.001V
0.1V
200mV 0.1mV
Input impedance: 10MΩ
- Overload protection: 200mV range: 250V DC or AC rms
2V-600V ranges: 600V DC or AC rms
- Frequency range: 40~400Hz
- Response: average (rms of sine wave)
- Max. input voltage: 600V AC rms
±(0.8% reading + 3dgt)
Measuring Range
Resolution
Accuracy
3.2.2 AC Voltage
600V
1V
±(1.0% reading + 3dgt)
