DIGITAL MULTIMETER
OPERATING INSTRUCTION
4.15.4 You can get reading from LCD.
NOTE:
• At the manual range mode, when only the figure ‘OL’ is
displayed, it indicates overrange situation and the higher
range has to be selected.
• For measuring resistance above 1MΩ, the meter may
take a few seconds to get stable reading.
• When the input is not connected, i.e. at open circuit, the
figure ‘OL’ will be displayed for the overrange condition.
4.16 MEASURING TEMPERATURE
WARNING
To avoid electrical shock, do not connect the
thermocouples with the electriferous circuit.
4.16.1 Set the transform
switch at the TEMP
range position.
4.16.2 ℃ range or ℉ range
can be transformed by
putting the ‘FUNC.’.
4.16.3 The LCD display will
show the current
environment temperature.
4.16.4 When measuring the
temperature with
thermocouple, ‘K’ type
probe for this meter can
be used. Insert the black plug to the COM jack and the
red one to the INPUT jack, touch the end of the
temperature sensor to the area or surface of the object
- 24 -
