DIGITAL MULTIMETER
DESCRIPTION
2. DESCRIPTION
- This meter is a portable professional measuring
instrument with handsome LCD and back light easily
reading.
- Single operation of a transform switch makes
measurement convenient. Overload protection and low
battery indication are provided, this meter is ideal for use
in the fields, workshop, school, hobby and home
applications.
- This meter has function of auto range and manual range.
- This meter has function of auto power off.
- This meter is with the functions of data hold and maximum
value hold.
- When using, it can show ranges engineering unit
enunciators measuring results.
2.1 NAMES OF COMPONENTS
⑴ LCD Display
⑵ ON/OFF Button
⑶ RANGE Button
⑷ FUNC. Button
⑸ Transform Switch
⑹ 10A Jack
⑺ INPUT Jack
⑻ COM Jack
⑼ Panel
⑽ Button
⑾ DATA-H Button
⑿ MAX.H Button
- 5 -
(1)
(2)
(3)
(4)
(5)
(6)
(10)
(11)
(9)
(7)
(8)
(12)
