28
DIGITAL MULTIMETER
OPERATING INSTRUCTION
for measurement.
4.16.5 You can get reading from LCD.
NOTE:
• With better hermetization, the meter’s temperature
measured circuit and environment need a little longer
time to reach heat balance, and then accurate reading
can be gotten.
4.17 MEASURING CAPACITANCE
WARNING
To avoid electric shock, be sure the capacitors have
been discharged fully before measuring the
capacitance of a capacitor.
4.17.1 Connect the black
test lead to the COM
jack and the red test
lead to the INPUT
jack.
4.17.2 Set the transform
switch at the desired
nF, 20μF or 2000μF
range position.
4.17.3 Auto range or
manual range can be
transformed by putting
the ‘RANGE’.
4.17.4 Before connect test
leads across two sides of the capacitor under
measurement, be sure that the capacitor has been
- 25 -
