DIGITAL MULTIMETER
DESCRIPTION
2.2 SWITCH, BUTTONS AND INPUT JACK ELUCIDATION
• ON/OFF Button
This Button is used to the switch of power.
• RANGE Button
This button is used to transform Auto range or manual
range.
• FUNC. Button
This button is used to transform function.
• DATA-H Button
This Button is used to the switch of data hold.
• MAX.H Button
This Button is used to the switch of maximum value hold.
• Button
This button is used to the switch of back light.
• Transform Switch
This switch is used to select functions and desired ranges.
•
10A Jack
Input terminal for current 0 ~ 10A
• INPUT Jack
Input terminals except 10A
• COM Jack
Common terminal for measurement
