Assembly Instructions
Step 7
Step 8
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
Attach the Lid Assembly (1) to
the body assembly by using
2 pcs Hinge Pin (C) and 2 pcs
Cotter Pin (D).
1
D
C
Attach the Lid Handle, Silver (4)
to the lid by using 2 pcs
M6 x 12 mm Bolt (A) and 4 pcs
Heat Insulation Washer (E).
Then unscrew the nut and washer
from the Thermometer (19) and
fix it to the lid with the washer and
nut again.
19
A
E
4
