© 2018 Pinnacle Climate Technologies, Inc. Silent Drive Forced Air Heater User’s Manual
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
13
PARTS LIST
Item # Description 150T-SDR 220T-SDR
11 Limit Control Bracket 70-019-1010 70-019-1010
12 Photocell 70-016-1000 70-016-1000
13 Photocell bracket 70-016-0101 70-016-0101
14 Air Draft Tube 70-300-0001 70-300-0001
15 Duct Bracket 70-300-0020 70-300-0020
16 Sirroco Fan 70-060-0001 70-060-0001
17 Duct Assembly 70-300-0100 70-300-0100
18 Motor Assembly 70-020-1000 70-020-1000
19 Motor Supporter 70-020-1010 70-020-1010
20 Blower Fan 70-024-1000 70-024-1000
21 Fan Guard 70-016-2000 70-016-2000
22 Ignitor 70-037-0350 70-037-0350
23 Side Cover 70-008-1100 70-008-1110
24 Power Cord 70-034-1000 70-034-1000
25 Return Fuel Line 70-036-0015 70-036-0015
26 Intake Fuel Line 70-036-1010 70-036-1010
27 Fuel Pump 70-400-0110 75-400-0110
28 Fuel Gauge 70-007-0215 70-007-0215
29 Fuel Cap 70-006-0140 70-006-0140
30 Fuel Filter 70-003-1000 70-003-1000
31 Drain Bolt 70-002-0115 70-002-0115
32 Rear Handle 70-043-1000 70-043-1100
33 Wheel Support Frame 70-041-1000 70-041-1100
34 Front Handle 70-043-1002 70-043-1102
35 Handle Bolts 70-043-1001 70-043-1001
36 Wheel 70-041-1400 70-041-1400
37 Wheel Axle 70-041-1510 70-041-1510
38 Wheel Nut 70-041-0550 70-041-0550
39 Safety Guard 70-065-1000 70-065-1000
40 Control Panel PCB 70-027-1005 70-027-1005
To Next Page
