© 2018 Pinnacle Climate Technologies, Inc. Silent Drive Forced Air Heater User’s Manual
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
4
SPECIFICATIONS
Model # 150T-SDR 220T-SDR
Rating: Btu/Hr 150,000 220,000
Fuel Consumption: Gal/Hr / L/Hr 1.14 / 4.32 1.67 / 6.32
Fuel Tank Capacity: Gallons / Liters 10 / 37.9 13 / 49.2
Pump Pressure: PSI / BAR 111 / 7.65 123 / 8.48
Volts: AC/Hz 120VAC ~ 60 Hz 120VAC ~ 60 Hz
Amps ≤3.15A ≤3.15A
Phase 1Ø 1Ø
Specifications subject to change without notice.
Tools Needed:
- Phillips head screw driver
- 8 mm open end wrench
- 19 mm open end wrench
Tip: Be sure to remove the axle from the
side of the Styrofoam packaging.
Tip: Use a power screwdriver and locking
wrench for easier assembly.
Axle
Rear Handle
Wheel Support Frame
Front Handle
50 mm Screws (8)
30 mm Screws (2)
8 mm Nuts (10)
Tires (2)
Safety Guard (1)
Axle Nuts (2)
Spacers (2)
Spare Drain Bolt (1)
WHAT’S IN THE BOX
Heater (1)
To Next Page
