Masterclock GMR1000 User Manual

NTP Driven Clocks
NTDS16
MASTERCLOCK, INC. 5-YEAR LIMITED PARTS & LABOR WARRANTY MADE IN THE USA
phone (USA and Canada): phone (international): email: online:
1-800-940-2248 +1-636-724-3666 sales@masterclock.com www.masterclock.com
GMR Series Options
Time Code Generator
SMPTE 12M
IRIG-B0
(DCLS, PWM)
IRIG-B1 (AM) IRIG-A (DCLS) IRIG-A (AM) IRIG-E (DCLS) IRIG-E (AM)
Rate
24, 25, 30 fps NDF
and 29.97 DF
1kHz, 1mS 1kHz, 1mS 10kHz, 0.1mS 10kHz, 0.1mS 100Hz, 10mS 100Hz, 10mS
Output Level @ 50 Ω
4 Vpp
(16 dBm)
5 Vp
(25 dBm)
5 Vpp
(18 dBm)
5 Vp
(25 dBm)
5 Vpp
(18 dBm)
5 Vp
(25 dBm)
5 Vpp
(18 dBm5
Mark to Space Ratio
N/A N/A 3.3:1 N/A 3.3:1 N/A 3.3:1
Gain 1 1 1
1 1 1 1
Number of Inputs
(SE: Single Ended - Unbalanced,
Dierential - Balanced)
1 SE, 1 DIFF 1 SE, 1 DIFF 1 SE, 1 DIFF 1 SE, 1 DIFF 1 SE, 1 DIFF 1 SE, 1 DIFF 1 SE, 1 DIFF
Type
NDF DCLS AM 1kHz DCLS AM 10kHz DCLS AM 100Hz
Encoding
None,
Leitch Date,
SMPTE 309M
None or IEEE 1344 year or IRIG STD 200-04
IRIG Coded
Expression
IRIG STD
200-04
0 BCDTOY, CF, SBS N/A B000 B120 A000 A130 E000 E110
1 BCDTOY, CF N/A B001 B121 A001 A131 E001 E111
2 BCDTOY N/A B002 B122 A002 A132 E002 E112
3 BCDTOY, SBS N/A B003 B123 A003 A133 E003 E113
4 BCDTOY, BCDYEAR, CF,
SBS (IEEE-1344 -
1995 Encoding)
N/A B004 B124 A004 A134 E004 E114
5 BCDTOY,BCDYEAR, CF N/A B005 B125 A005 A135 E005 E115
6 BCDTOY,BCDYEAR N/A B006 B126 A006 A136 E006 E116
7 BCDTOY,BCDYEAR, SBS N/A B007 B127 A007 A137 E007 E117
The Time Code Generator option for the GMR Series generates SMPTE or IRIG-B time codes, as well as IRIG-A and IRIG-E waveforms.
The TCG option is software controlled and locks to GPS satellites, Time Code Reader, NTP Client, and/or High-Stability Oscillator.

Masterclock GMR1000 Specifications

General

Brand	Masterclock
Model	GMR1000
Category	Control Unit
Language	English
