Alpha Pro charge regulator – User and Installation Manual
21
Value
Meaning
Default
Adjustable range
Temp.
compensate
4
Voltage change at temperature rise/decrease
-0.030V/°C
-1.000 - +1.000
Bulk
4
Voltage
Bulk voltage
14.25V
6
8-16V
6
Minimum time
Minimum bulk voltage timer
2 min
0-600 min
Start time at
Voltage at which to start the minimum bulk voltage
timer
13.25V
6
8-16V
6
Maximum time
Maximum bulk voltage timer
480 min
0-600 min
Return voltage
Return to bulk voltage
12.80V
6
8-16V
6
Return time
Adjustable Return to Bulk time after the Return to
Bulk voltage has been reached.
30 sec
0-255 sec
Absorption
4
Voltage
Absorption voltage; Do not adjust the charge
voltage above the recommended limits of the
battery manufacturer.
14.25V
6
8-16V
6
Maximum time
Maximum absorption timer
Examples of cases when to adjust:
• Extension of the absorption time to do some
intentional overcharging to regain lost capacity.
• Shorten the time if you stop and start the engine
often each day.
• Temporary time reduction for testing purposes.
240 min
0-600 min
Float
4
Voltage
Float voltage; If the float voltage is set near 13.0V,
you may have to switch on some DC loads to get
the alternator to turn on because it takes some
time for the voltage to settle from the higher
absorption voltage.
13.25V
6
8-16V
6
Alarm settings
4
High alarm on
Alarm DC High on
15.25V
6
8.30-16.00V
6
High alarm off
Alarm DC High off
14.75V
6
8.20-15.90V
6
Low alarm off
Alarm DC low off
11.00V
6
8.10-15.80V
6
Low alarm on
Alarm DC low on
10.00V
6
8.00-15.70V
6
Alarm delay
Alarm delay time
30 sec
0-240 sec
Low field curr.
Option to allow or suppress the "low field current"-
alarm
Suppress
alarm
Allow alarm/
Suppress alarm
Shunt
Shunt device
Selection of the shunt to measure the battery voltage, see Section 6.3.8.
Alpha Pro setup
Factory reset
Option to reset to factory settings
Lock setup
Button to lock the configuration settings. With the configuration locked, only the language
and device name can be changed.
1
Only in combination with alternator temperature sensor.
2
All RPMs in this group are Alternator RPMs.
3
The number of Pool pairs is only needed if RPM values are required in MasterBus.
4
Can be modified if battery type is "User defined".
5
This will force the field current to 0%. Note: with older firmware it would not drop below 20%. Therefore, the new behavior of
this setting may affect existing installations. An external tachometer would read 0 RPM while the alternator is still spinning!
6
For a 24V system, multiply the voltages by two.
