Live Data Mode
RECORDING (CAPTURING) LIVE DATA
MD70 65
Record by DTC Trigger
This function automatically records (captures) Live Data information
when a DTC sets and saves it in the FixAdvisor’s memory. The
recorded (captured) data can be a valuable troubleshooting aid,
particularly if you are experiencing a fault that is causing a DTC to set.
1. While linked to the vehicle, start the engine,
then press and release the M button.
The Main Menu displays.
2. Use the UP
and DOWN buttons,
as necessary, to highlight Live Data Menu,
then press the ENTER
button.
The Live Data Menu displays.
3. Use the UP
and DOWN buttons,
as necessary, to highlight Record Live
Data, then press the ENTER
button.
The Record Live Data Menu displays.
4. Use the UP
and DOWN buttons,
as necessary, to highlight Record by DTC
trigger, then press the ENTER
button.
The Select Data Set screen displays.
You can record the entire Live Data list
or a custom Live Data list.
To record the entire Live Data list, use
the UP
and DOWN buttons, as
necessary, to highlight Entire Live
Data List, then press the ENTER
button. Proceed to step 7.
To record a custom Live Data list, use
the UP
and DOWN buttons, as
necessary, to highlight Custom Live
Data List, then press the ENTER
button. The Record Custom Live Data
menu displays, with the first PID in the
menu highlighted. Proceed to step 5.
