Matrix A7X-01 User Manual

38
9.1 FRONT DISK REPLACEMENT
CHAPTER 9: PART REPLACEMENT GUIDE
FIGURE E
4) Rest the link arm padded surface on the front stabilizer (Figure E).
5) Press the center cap and turn it counter clockwise to remove (Figure F).
6) Remove the 24mm locking nut and washer by turning them counter clockwise (Figure G).
FIGURE F
FIGURE G
