73
FIGURE E FIGURE F
FIGURE G FIGURE H
10.5 TV PROGRAMMING INSTRUCTIONS - CONTINUED
CHAPTER 10: ASCENT TRAINER SPECIFICATIONS AND ASSEMBLY GUIDE
6) Then go down to CHANNEL SCAN and use the volume button to select it (Figure E).
7) Move the cursor down to START TO SCAN and use the volume button to select it (Figure F).
8) If the channels are now coming in clearly, press the BACK key to return to normal operation (Figure G).
9) If the channels still are not coming in, or are showing in black and white, return to CHANNEL SCAN, and then change the CABLE SYSTEM
to match your incoming cable frequency (Figure H). Re select START TO SCAN once this has been changed.
10) If the channels are still not coming in clearly, refer to the TV Troubleshooting in Section 8.5.
