78
11.4 INSTALLING ADJUSTABLE TENSIONER - CONTINUED
9. Thread the two cable ties through the bottom holes in the
alignment block and around all of the components.
10. Grab the tail end of each cable tie and pull the cable tie VERY
tight, stretching it around the components. As the cable tie is held
tight, push the zipper portion toward the roller to lock the tension in.
11. Grasp the pulley on the opposite side of the machine from the
small pulley and rotate it back and forth slightly to confirm that the
components are all seated tightly against each other.
12. Grasp the pulley on the opposite side of the machine from the
small pulley and rotate this back and forth slightly and gently as
you make these bolts finger-tight. Finger-tighten the 2 bolts on the
bottom of the bracket assembly and then the three bolts on the side.
CHAPTER 11: UPGRADES
