CHAPTER 8: TROUBLESHOOTING
8.16 TROUBLESHOOTING - NO RESISTANCE ISSUE
FIGURE A FIGURE BFIGURE A FIGURE B
NO RESISTANCE TROUBLESHOOTING
1) SYMPTOM:
No resistance
2) SOLUTION:
1) Check the power resistance wire connection between the power resistor and LCB (Figure A).
2) Check to see if the resistor wire has resistance (Figure B).
--If there is no resistance (ohms) reading, replace the power resistor.
--If there is resistance, replace the LCB.
