8.18 TV TROUBLESHOOTING - OVERVIEW
CHAPTER 8: TROUBLESHOOTING
FIGURE C
The Matrix 7xi Ascent Trainer includes an integrated TV that shows in the large display window. The TV is capable of being shown as a 9" or
12" screen (Figures A & B). The console should be equipped with an entertainment keypad similar to Figure C.
FIGURE A
FIGURE B
FIGURE C
