10
P
AR
T 1: USER FRAME ASSEMBL
Y
S
TEP 1
| WEIGHT S
T
A
CK INS
TRUCTIO
NS & NO
TE
S
ID
DESCRIPTION
QUANITY
1
Lower Connecting Tube
1
2
M10 X 30L
SHC
4
3
M10 Flat W
asher (25 mm Diameter)
12
4
Weight Stack
1
5
M10 Nylock Nut
4
6
M10 X 75L
SHC
4
7
Upper Connecting Tube
1
Install the user frame hardware as shown, but DO NOT FULL
Y
TIGHTEN .
ASSEMBL
Y
3
4
2
1
6
5
7
