23
STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES
PART 5: PL ASTICS ASSEMBLY
ID DESCRIPTION QUANITY
38 Left Front Shroud 1
39 Rear Shroud 1
40 Right Front Shroud 1
ASSEMBLY
Install the weight stack shrouds as shown.
39
38
40
