22
ASSEMBLY
STEP 2 | BACK PAD & HEAD PAD ASSEMBLY INSTRUCTIONS & NOTES
PART 4: PAD ASSEMBLY
ID DESCRIPTION QUANITY
35 Head Rest Assembly 1
36 M10 X 75L BHC 4
37 Back Pad Assembly 1
37
35
36
Install the pad as shown.
Tightento27N-m/20ft-lbs.
