Parts List
ID
DESCRIPTION
QTY
1 Lower Connecting Tube 1
2 M10 X 30L Socket Head Cap Screw 6
3 M10 Flat Washer (25 mm Diameter) 22
4 Weight Stack 1
5 M10 Nylock Nut 9
6 M10 X 75L Socket Head Cap Screw 8
7 Upper Connecting Tube 1
8 M10 X 170L Socket Head Cap Screw 2
9 User Frame 1
10 M10 Saddle Washer 2
11 M10 X 25L Socket Head Cap Screw 6
12 M10 Flat Washer (22 mm Diameter) 14
13 Foot Plate Assembly 1
14 Foot Plate Cover 1
15 M6 Flat Washer 4
16 M6 X 16L Button Head Cap Screw 4
17 M10 X 105L Socket Head Cap Screw 1
18 CAM 1
19 M8 Nylock Nut 16
20 M8 Flat Washer 16
21 Linear Bearing Block 4
22 M8 X 30L Socket Head Cap Screw 16
23 Seat Sled 1
24 Rubber Bumper Stop 2
25 Snap Ring 4
26 Disc (45 mm Diameter) 4
27 Guide Rod Sleeve 4
28 Guide Rod 2
29 End Cap 2
30 ROM Assembly 1
31 M10 X 20L Socket Head Cap Screw 6
32 M8 X 25L Shoulder Bolt 1
33 Pad 1
