Matrix S-Drive User Manual

16
5.7 fronT roller rePlacemenT - conTinUeD
4)Removethescrewfromflywheelset(FigureD).NOTE: Fix the front roller axle before removing the flywheel screw.
5)Useacrankpullertoolstoremoveflywheelset(FigureE).
NOTE:
5-1Pleasebuythecrankpullerinyourlocalmarket.
5-2Fixthefrontrolleraxlebeforeremovingtheflywheelset(FigureF).
6)Theflywheelsetisveryheavy,sowhenyoutakeoffflywheelfromfrontrolleraxle,becarefulnottodroptheflywheelsetastheringwillbe
easilydamaged(FigureG).
fiGUre f
fiGUre G
cHaPTer 5: ParTS rePlacemenT GUiDe
fiGUre D
fiGUre e
