Matrix SATATYA PARAM NVR8S User Manual

Matrix SATATYA NVR Quick Start 9
Ports and Connectors
General Specifications
Interface Description All Variants
USB 1
(Upper)
USB 2.0, used for Scheduled Backup.
To connect USB Mouse.
To connect Dongle.
Yes
Ratings: 5VDC - 500mA
USB 2
(Lower)
USB 2.0, used to connect USB Mouse.
To connect Dongle.
Yes
Ratings: 5VDC - 500mA
USB 3
USB 3.0, used for Manual Backup.
To connect USB Mouse.
To connect Dongle.
Yes
Ratings: 5VDC - 900mA
Alarm In
(Terminal Block Plug)
To connect a sensor device to detect
alarm events.
Yes (2)
Alarm Out
(Terminal Block Plug)
To connect an alarm sounding relay
device such as a hooter or siren.
Yes (1)
HDMI 2.0
To connect a high definition digital
monitor or TV for Main view.
Yes (1)
LAN
(RJ45)
To connect a standalone personal
computer, or a LAN Switch, or to connect
to the Internet over a DSL Modem or
Router.
Ethernet Speed:10/100/1000Mbps
LAN 1 - Present in all variants
LAN 2 - Present in all variants except
NVR0801X and NVR1601X
Audio In
(RCA)
To connect audio input device such as a
mic.
Yes (1)
Audio Out
(RCA)
To connect a low impedance earphone,
active sound box or an amplified speaker.
Yes (1)
Reset
Press and hold down the reset button for
atleast 4 seconds to default
the following parameters.
• LAN Settings
• User Settings
• General Settings
Yes
Parameters
NVR0801X, NVR1601X, NVR1602X,
NVR0801X P2, NVR1601X P2, NVR1602X
P2, NVR3202X, NVR3202X P2
NVR3204X, NVR6404X,
NVR6408X, NVR3204X P2,
NVR6404X P2, NVR6408X P2,
NVR9608X P2
Power Supply 12VDC, 5A SMPS
Operating Temperature 0°C to +50°C (32°F to 122°F)
Humidity 5% to 95% RH Non-Condensing

Matrix SATATYA PARAM NVR8S Specifications

General

Brand	Matrix
Model	SATATYA PARAM NVR8S
Category	Security System
Language	English
