34 Matrix SATATYA NVR Quick Start
GSM Dongle
• Connect the GSM dongle to the USB port as described in “Ports and Connectors”.
Connecting Wires to the Terminal Blocks
• Connections to the Alarm Input and Alarm Out Ports are to be made using the Terminal Block
Plugs provided to you in your package.
Wire Range of the Terminal Block plugs is 28-16 AWG (0.5 -1.5mm
2
).
Connecting Power Supply
The AC input to the Universal Power Supply Adapter can be 100-240VAC@50- 60Hz. It is
advisable to route the power supply from the mains through a Uninterrupted Power
Supply (UPS) for continuous operation.
• If you have completed all the connections you want to make, plug the Power Adapter into the
power outlet. Switch on the power supply. Wait for the reset cycle to complete.
To Power On Device
NVR0801X, NVR1601X, NVR1602X,
NVR0801X P2, NVR1601X P2, NVR1602X P2,
NVR3202X, NVR3202X P2
NVR3204X, NVR6404X, NVR6408X,
NVR3204X P2, NVR6404X P2,
NVR6408X P2, NVR9608X P2
Power Supply 12VDC, 5A SMPS
To Power On Device NVR0401XS P2/NVR0801XS P2, NVR1601XS P2
Power Supply 12VDC, 2A
