10 Matrix SATATYA NVR Quick Start
LED And Buzzer State
The NVRX/NVRX P2 variants has a set of LEDs and Buzzer for indication of events on the SATATYA
NVRX/NVRX P2 series. It has been explained in the table below.
State Description Status LED Cadence
Power
LED
Buzzer (System)
Supply is connected but application is not
yet initialized.
OFF
Green
Steady
N.A.
On Application Initialization
Red
1000 - ON and 1000 – OFF
3000 – ON
System in normal state (Connected to
network).
Green
500 - ON and 500 – OFF
N.A.
Storage Incomplete Volume.
Red
1000 ON–5000 OFF
1000 - ON and 5000 – OFF
Storage Full Alert.
Red
2000-ON–2000 OFF
N.A.
Storage Full.
Red
1000 ON–3000 OFF
N.A.
Formatting Disk.
Red
1000 ON–1000 OFF
N.A.
Firmware upgrade in process.
Orange
(ON till firmware upgrade
process completes)
N.A.
Firmware upgrade failed.
Red
1000 ON–1000 OFF
1000 - ON and 1000 – OFF
Recording failed for 1 or more enabled
cameras (Not all)
Orange
(500 – ON and 500 – OFF)
ON till recording of all
enabled cameras gets
started
N.A.
Recording failed for all enabled cameras
Red
(Steady Light till recording
of any one enabled camera
gets started)
N.A.
Trigger from Event
Green
500 - ON and 500 – OFF
3000 - ON and 1000 – OFF
Backup Device full
Green
500 - ON and 500 – OFF
1000 - ON and 2000 – OFF
No Backup Device
Green
500 - ON and 500 – OFF
1000 - ON and 3000 – OFF
