56 Matrix SATATYA NVR Quick Start
Frame Rate: Click the picklist and click again to select the desired Fame Rate option.
Resolution: Click the picklist and click again to select the desired Resolution option.
The Stream Resolution of selected IP Camera will be displayed in the Resolution list. In
case, you have configured the ROI (Region Of Interest) in the running Stream Profile of
the IP Camera then, the Stream Resolution of that particular Stream will be displayed in
the Resolution list.
The camera streams with custom resolution of minimum 64pixels and maximum
8192pixels will be displayed in the Live View.
The VGA resolution, that is 640x480 is supported in all Matrix Cameras supported by
NVR/NVRX, except the following:
• SATATYA CIBR13FL40CW
• SATATYA CIDR13FL40CW
• SATATYA CIDRP20VL130CW
• SATATYA CIBR30FL36CG
• SATATYA CIBR30FL60CG
• SATATYA CIDR30FL36CW
• SATATYA CIDR30FL60CW
Bit Rate Type: Click the desired radio button — Constant Bit Rate (CBR) or Variable Bit Rate
(VBR).
Bit Rate: Click the picklist and click again to select the desired Bit Rate option.
Quality: Click the picklist and click again to select the desired Quality option. Selecting higher
settings will give you higher quality video, at the expense of network bandwidth and disk storage
capacity.
GOP: Configure the desired GOP from 1 to 100.
Audio: Select this check box if you wish to enable Audio in synchronization with the video for the
stream type of selected camera. Clear to disable.
Search Camera
As per the configuration of the LAN parameters, the cameras in the network will be displayed with
the following details — IP Address, HTTP Port, Brand Name, Model Name, ONVIF (that is added
via ONVIF then check box will be selected), ONVIF Port, Add and Test — on this page.
