8.5 ERROR MESSAGE TROUBLESHOOTING
ERROR MESSAGES - 0x01A2, 0x01A0, 0x0140, and 0x01A1.
1) CAUSE - Incline direction is reversed.
2) SOLUTION:
a. Check that the incline motor cable is connected at the MCB.
b. Press "ENTER 2001 ENTER". The display should now read Engineering Mode.
c. Press the Calibration Tab, then press START. If the calibration passes, delete the error log, unit is operational.
e. IF AUTO CALIBRATION FAILS, press MANUAL CAL ELEVATION MIN and press START (Figure A).
f. Check to see if the LED UP and DOWN lights are lit on the MCB as you change the Elevation Minimum. If LEDs are not lit, check the
console cable and console. If LEDs are lit, replace the incline motor (Figure B).
g. If incline motor does not resolve issues, replace MCB.
FIGURE A
FIGURE B
CHAPTER 8: TROUBLESHOOTING
