Matrix U3x-01

24
8.4 CUP HOLDER REPLACEMENT
CHAPTER 8: PART REPLACEMENT GUIDE
1) Locate the cup holder on the back of the console (Figure A).
2) Pull up and remove the cup holder (Figure B).
3) Reverse Steps 1-2 to install a new cup holder.
FIGURE A
FIGURE B
