42 Matrox Maevex Series – User Guide
Maevex 5150 Encoder
Maevex 5150 encoder
Product type
Standalone appliance
Video input connector 1
× HDMI
Video output connectors 1
× HD-15 (VGA) + 1× HDMI
Audio input connector 1× mini-stereo jack
Audio output connector 1× mini-stereo jack
Network connector 1× RJ45
RS232 connector 1× DE9 (also known as DB9) – female
Video stream output MPEG-4 Part 10 / AVC (H.264)
Audio stream support
MPEG4-GENERIC (firmware version newer than 1.03.03),
MPEG4-LATM (up to firmware version 1.03.03)
Streaming protocols RTP, RTSP, RTCP, UDP
Command protocols TCP/IP, UPnP, HTTPS
Supported resolutions (input)
*†‡
* All supported resolutions have a vertical refresh rate of 60 Hz.
† When using a display resolution equal to or higher than 1280×720p60, we recommend you use certified high-speed HDMI
cables.
‡ When pass through is enabled, only the resolutions supported by your monitor may be available.
1920 × 1200, 1920 × 1080, 1680 × 1050, 1600 × 1200,
1600 × 900, 1440 × 900, 1400 × 1050, 1360 × 768,
1280 × 1024, 1280 × 960, 1280 × 720, 1024 × 768,
800 × 600, 720 × 576, 720 × 480, and 640 × 480
Supported resolutions (output)
1920 × 1200, 1920 × 1080, 1680 × 1050, 1600 × 1200,
1600 × 900, 1440 × 900, 1400 × 1050, 1366 × 768,
1360 × 768,1280 × 1024, 1280 × 960, 1280 × 768,
1280 × 720, 1024 × 768,852 × 480, 848 × 480,
800 × 600, 720 × 576, 720 × 480, and 640 × 480
Additional supported HDMI
resolutions
†
1080p50, 1080p30, 1080i60/50
§
,
720p50, and 576p50
§ Interlaced resolutions are only supported at input. When using interlaced resolutions, the capture rate selection is disabled
and your encoder automatically captures all frames.
Maximum unicast connections
¶
¶ With a resolution of 1080p at 15Mb/s.
8
Power requirements 5V DC, maximum 5 A (5 A fuse for overcurrent protection)
Power connector DIN 4 female (4-pin)
Power consumption
Maximum: 9 W
**
Minimum: 6 W
** With a stream of 1080p60 at 25Mb/s.
Dimensions
21.59 cm × 2.59 cm × 10.16 cm /
8.50 in × 1.02 in × 4.00 in
Certifications Class B: ACMA, CE, FCC, ICES, VCCI, Korea
