Chapter 2 Explanation Equipment
- 7 -
The title of the machine
The state of goods arrival
○Input and output stand
○4 capped bolts(forming
machine for input and output)
○4 bolts with 6 angles
○4 screw caps with 6 angles
○4 flat brushes
(those above are used to fix
drying funnel and output stand)
Picture 4
The picture show HD-25～100type
On occasion of base-connected installation, the
input and output stand receives goods in the state
of whole set.
○Accessory
○Cooling water tube (rubber tube)
……………………φ10×5m×2root
○Connecting hose (heat resistant
hose) ……………………5m×2root
○Hose strap……………4pieces
※On the occasion of
DMS2-170,240,DMZ2-80,120
Connecting hose (heat resistant
hose)………………………2m×2root
Hose strap………………4pieces
(Connecting hose and Hose strap are
option parts.)
※Hold in two bags。
※The connecting hose is the exhaust of the
dehumidifying unit, and is the drying funnel
is exhaust and air intake pipe connecter
with IN,OUT.
