Chapter 9 Technical manual
- 61 -
1. The shipment setting value for the controller
Note ※1 Must be set when assemble the transportation equipment. It may be ignored in standard
condition.
The parameter for the user setting mode
Of pushing SV switch every, the parameter indicator switches over. But when pushing SV switch more
than 5 seconds, changes to the engineering setting mode. Be careful.
Use Character Setting range
initial
setting value
Dry temperature SV
0～350℃
80℃
Start-up timer DLY
0.0～99.5 hour
0.0 hour
NO.1 Convey time※1
Fd1
0～999 sec.
20 sec.
NO.2 Convey time※1
Fd2
0～999 sec.
15 sec.
NO.3 Convey time※1
Fd3
0～999 sec.
15 sec.
NO.1 Discharge time※1
dc1
0～999 sec.
25 sec.
NO.2 Discharge time※1
dc2
0～999 sec.
25 sec.
NO.3 Discharge time※1
dc3
0～999 sec.
25 sec.
NO.2 Raw material beginning time※1
bt2
0～99 sec.
8 sec.
NO.3 Raw material beginning time※1
bt3
0～99 sec.
8 sec.
The parameter for the engineering setting mode
When pushing SV switch more than 5 seconds, changes to the engineering setting mode. Of pushing
SV switch every by the engineering setting mode, the character switches over.
Use Character Setting range
initial
setting value
Upper limit temperature alarm detection delay time ULt
0～999 sec.
5 sec.
Feed 1 Convey malfunction detection count ※1
LCt
0～999 count
50 count
Dry unit level gage malfunction count ※1
FCt
0～999 count
20 count
Feed 1 Convey malfunction detection delay time※1
1Ed
0～999 min.
120 min.
Feed 2 Convey malfunction detection delay time※1
2Ed
0～999 sec.
180 sec.
Feed 3 Convey malfunction detection delay time※1
3Ed
0～999 sec.
180 sec.
Upper limit temperature alarm
(dry temperature deviation)
dUS
0～40℃
10℃
Upper limit temperature alarm
(regeneration temperature deviation)
rUS
0～40℃
10℃
Dry system broken detection time (dry) dLP
0～999 min.
0 min.
Regeneration system broken
detection time (regeneration)
rLP
0～999 min.
0 min.
Feed1 Level switch demand delay ※1
L1d
0～999 sec.
3 sec.
Feed2 Level switch demand delay ※1 L2d 0～999 sec. 3 sec.
Feed3 Level switch demand delay ※1
L3d
0～999 sec.
3 sec.
Reverse phase Detection function rst
0～1
1
