Matsui DMS2-80 - Equipment Composition

Chapter 2 Explanation Equipment
- 4 -
2. Equipment Composition
The device consists of the recorded machines and apparatuses. Please refer to
the types of this item and device brand to Confirm that type you want to
purchase.
< Type example >
DMS2-80①-25②-③
Drying filter capacity
Classifying mark of the dehumidification unit
① Technical criterion of drying temperature<the set upper limit
of the drying temperature>
Mark Drying temperature
The set value of
upper limit
No mark Standard type
130℃
H High temperature type
180℃
② The structure of the drying funnel
Mark The structure of the drying funnel
No mark Signal (one scale type)
D Incubation type (two scale type)
③ Setting ways of the drying funnel
【Notice!】
The cyclic from of the dehumidifying air is only the setting of cyclic description
(Half-circulation and a one path cannot be set up.)
Mark Setting ways
No mark
Direct installation of shaping machine
(separable type)
V Pallet of the drying funnel (pallet type)
