Chapter 3 Installation
- 32 -
2. The connection of the power supply
Step
Item Task
1
Connecting
relay cord
Connect relay cord of dehumidifying unit to relay box of drying hopper
side. (Only for dehumidifying unit ,drying hopper separable type)
DMS2-170,240
DMS2-80,120/DMZ2-40～120
Relay box inside
H
1
H
2
H
3
+
K
-
K1
R
21
1
H
4
H
5
H
6
+
K1
-
K1
R
21
1
H
3
H
2
H
1
Picture 35
【Caution！】Be sure that it is fixed securely with machine screws and
connected without looseness to each terminal inside relay
box.
