Chapter 3 Installation
- 33 -
Step
Item Task
2
Connecting
power cord
Make sure that power breaker on control panel is turned “OFF” and
then connect power cord (5m) to power supply of the equipment at
your company.
R phase･････ Red
Power cord･･･S phase･････ White････For primary power supply
T phase･････ Black
E･･･････ Green････････For grounding (earth)
【Caution!】
·Power breaker on control panel must be turned “OFF” before
connecting power cord.
·Fasten the connection securely and make sure that there is
no looseness.
·Be sure to connect the grounding.
·Power supply should be set securely to tap with grounding
terminal.
To Next Page
