Chapter 2 Explanation Equipment
- 10 -
<Drying hopper>
－－－ HD-10,15,25,50 type －－－
Picture 8
U-bolt
Temperature sensor
Hook plate for lifting
Thermostat
Suction pipe
Heater box
Relay box
Heater cord
Power cord
（Relay cable）
Exhaust pipe
Catchclips（3）
Catchclips (2)
Conical section
Base
Cylindrical section
Level glass
HD-10,15type
Lid
Base
Slide gate
Material outlet
HD-25,50type
Set pin
Separator
Diffuser
Hot air pipe
Hopper inside
Warning label
Power supply sticker
