Chapter 2 Explanation Equipment
- 12 -
<Drying hopper>
－－ HD-250,300 type －－
Base
Lid
Suction pipe
Heater box
Relay box
Heater cord
Relay cord
Conical section
Cylindrical section
Level glass
HD-250,300type
Slide gate
Temperature sensor
thermostat
Set pin
（Handle）
Diffuser
Hot air pipe
Warning label
Power supply sticker
Exhaust pipe
Material outlet
Picture 10
