Matsui DMS2-80 - Page 69

Chapter 11 Specifications
- 65 -
Type DMS2- 80 120 170 240
Control Drying temperature adjustment PID control
Regeneration temperature
adjustment
PID control
Out automatic start timer
Set up times (10minute～99hour50minute)
Over-temperature (drying regeneration)
Motor over-load
(Drying)(Drying regeneration)
Running prevention
Alarm protection loop
Cooling delay when stopping
Power supply
AC200V 50/60Hz，220V 60Hz，380V 50/60Hz，415V
50/60Hz 3P
Operation return loop voltage
50Hz/60Hz
AC200/220V, 1 P
200V～240V
20（32） 32（40） 40（50） 50（63）
Capacity of power
breaker (A)
380V～415V 10（16） 16（20） 20（32） 32（40）
Weekly timer
Electricity leakage breaker
Dew point indicator
Upper limit of drying temperature alarm
Different voltage
Compatible
option
Transport control
W mm 440 500
D mm 570 704
Outer
dimensions
H mm 1410
Weight kg 120 130 160 200
Capacitance
(Max.)
KVA
7.36(8.96) 8.26(10.96) 11.56(15.36) 14.79(20.35)
Note) Descriptions in ( ) are for high temperature specifications.
