Appendix
- 79 -
Type：DMZ2-40,80,120A Marker： 50Hz/60Hz (High temperature) φ3
NO. Code Name Specifications Number Remark
NF63-CW 3P 10A(16A)(40)
NF63-CW 3P 16A(20A)(80)
NF63-CW 3P 20A(32A)(120)
MITSUBISHI
380V/415V
NF63-CW 3P 20A (40)
NF63-CW 3P 32A(40A)(80)
1 NFB-1 Breaker
NF63-CW 3P 40A(50A)(120)
1
MITSUBISHI
200V/220V
2 Terminal Cap TCS-05SW3W 1 MITSUBISHI
3 V Operation Hander V05SWEF 1
Red/Yellow for
anon stop
4 MS-1 Contactor SC-03 AC200V 1 FUJI
5 MC-0 Contactor SC-4-1 AC200V 1 FUJI
6 SSR-1 Solid relay TSR-25DA-H 1 YangMing
7 SSR-2 Solid relay TSR-25DA-H 1 YangMing
8 Radiator TSR-100 2 YangMing
TR-ON/3(0.95-1.45A) (40)
TR-ON/3 (2.2-3.4A) (80)
TR-ON/3 (4-6A) (120)
1
FUJI
380V/415V
TR-ON/3 (1.7-2.6A) (40)
TR-ON/3 (4-6A) (80)
9 OCR-1 Thermal relay
TR-ON/3 (6-9A) (120)
1
FUJI
200V/220V
10 SK1 Auxiliary contact SZ-A20 1 FUJI
11 SK2 Auxiliary contact SZ-A40 1 FUJI
12 F-1 Fuse(Pedestal) TFB101N 3A 1 Taiwan Tiande
13 CR-1 Relay
MY4J AC220V/PYF-14A
1 OMRON
14 TH-1 Over-temperature relay
TS-200S 1 SuZhou Zhihe
15 TH-2 Over-temperature relay
A255℃
1 NGT(Japan)
16 Tr-1 Transformer
JBK3-300 AC380,400,415
/200V
JBK3-300 AC220/200V
1
WuXi
(Only 220～415V
have)
