Operation
Maverick MK2 Spot User Manual Rev. 4 -15-
Pan/Tilt Angle
Range
To set the range of motion the pan or tilt is permitted:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select Pan Angle or Tilt Angle
, or touch the display where it says the
2.
desired setting.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select 540 (540°), 360 or 270 (360° or 270° for 4.
pan or tilt respectively), 180 (180°), or 90 (90°) or touch the display where it says the desired
option.
Press <ENTER>.
5.
Blackout on
Pan/Tilt
Movement
To set whether the product will black out during pan or tilt movement, follow the instructions below:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select BL. O. P/T Move, or touch the display where it says
BL. O. P/T
2.
Move.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (do not black out) or YES (black out 4.
during movement), or touch the display where it says the desired option.
Press <ENTER>.
5.
Blackout on Color
Movement
To set whether the product will black out during color movement, follow the instructions below:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select BL. O. Color Move, or touch the display where it says BL. O. 2.
Color Move.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (do not black out) or YES (black out 4.
during movement), or touch the display where it says the desired option.
Press <ENTER>.
5.
Blackout on Gobo
Movement
To set whether the product will black out during gobo movement, follow the instructions below:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select BL. O. Gobo Move, or touch the display where it says BL. O. 2.
Gobo Move.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (do not black out) or YES (black out 4.
during movement), or touch the display where it says the desired option.
Press <ENTER>.
5.
Touchscreen
Calibration
If the touchscreen is not responding correctly, it may need to be calibrated. To do so:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select Calibration, or touch the display where it says Calibration. 2.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (do not calibrate) or YES (calibrate), 4.
or touch the display where it says the desired option.
Press <ENTER>. 5.
Follow the instructions, touching the points as they appear on the display.
6.
Touchscreen Lock
To lock or unlock the touchscreen control panel, do the following:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select Touchscreen Lock, or touch the display where it says 2.
Touchscreen Lock.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (display will respond to touch) or YES 4.
(display will not respond to touch), or touch the display on the desired option.
Press <ENTER>.
5.
