Operation
-16- Maverick MK2 Spot User Manual Rev. 4
Lock the Screen
To lock the touchscreen control panel and menu buttons, do the following:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select Lock Screen, or touch the display where it says Lock Screen. 2.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (display will respond to touch or 4.
buttons) or YES (display will not respond to touch or buttons), or touch the display where it says
the desired option.
Press <ENTER>. 5.
To unlock the touchscreen and menu buttons, do the following:
Touch the display touchscreen anywhere or push any menu button. 1.
Enter the passcode (0920) using the touchscreen or buttons.
2.
Swap Pan and Tilt
To switch the pan and tilt functions so that what normally controls the pan controls the tilt and what
normally controls the tilt controls the pan, follow the instructions below:
Navigate to the Settings menu.
1.
Use <UP> or <DOWN> to select Swap XY, or touch the display where it says Swap XY. 2.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (normal pan and tilt) or YES (pan 4.
controls tilt, tilt controls pan), or touch the display where it says the desired option.
Press <ENTER>.
5.
Pan/Tilt Speed
To set the maximum speed of the pan and tilt:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select XY Mode, or touch the display where it says XY Mode. 2.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Slow or Fast, or touch the display where 4.
it says the desired option.
Press <ENTER>.
5.
WDMX Reset
To reset the WDMX connection from the Maverick MK2 Spot, do the following:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select WDMX Reset, or touch the display where it says WDMX 2.
Reset.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (do not reset connection) or YES 4.
(reset the connection), or touch the display where it says the desired option.
Press <ENTER>.
5.
Backlight Timer
To set the amount of time after inactivity before the display backlight turns off:
Navigate to the Settings menu. 1.
Use <UP> or <DOWN> to select Backlight Timer, or touch the display where it says Backlight 2.
Timer.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select 30S (after 30 seconds of inactivity), 1M 4.
(after 1 minute of inactivity), 5M (after 5 minutes of inactivity), or 30M (after 30 minutes of
inactivity), or touch the display where it says the desired option.
Press <ENTER>.
5.
Loss of Data
In case of an input signal being lost in any way, the Maverick MK2 Spot will respond in one of two
ways. The product will either hold the last signal received, or black out all LED output.
To set which way the product responds, follow the instructions below:
Navigate to the Settings menu.
1.
Use <UP> or <DOWN> to select Loss of Data, or touch the display where it says Loss of Data.
2.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Hold (hold last signal received) or Close 4.
(black out all LED output), or touch the display where it says the desired option.
Press <ENTER>.
5.
