MAXA R407C - Page 12

CD 30 ÷ 520
12
CD
Model
290 325 355 390 420 455 485 520
KW 325 355 390 420 455 485 520 240
Cooling
Capacity
*1000 kcal/h 279.5 305.3 335.4 361.2 391.3 417.1 447.2 206.4
KW 345 377 414 446 483 515 552 256
Heating
capacity
*1000 kcal/h 296.7 324.22 356.04 383.56 415.38 442.9 474.72 220.2
Cooling input kW 96 107.5 117.5 129 139 150.5 160.5 172
Heating input kW 93.8 105 114.8 126 135.8 147 156.8 168
Power
380V 3N 50Hz
Control type Wire control
Safety protection device
High/low-pressure switch, anti-frost switch, water-flow switch, over-load
protection, and power phases sequence protection.
30kW master+65kW master+
65 kW auxiliary modules
1+0+4 0+1+4 1+0+5 0+1+5 1+0+6 0+1+6 1+0+7 0+1+7
Compressor input kW 83 92.5 101.5 111 120 129.5 138.5 148
Refrigerant R407C
Refrigerant kg 4.5*16 4.5*20 4.5*22 4.5*24 4.5*26 4.5*28 4.5*30 4.5*32
Water flow volume
m
3
/h
13.89 15.56 17 18.67 20.11 21.78 23.22 24.89
Water resistance
loss kPa
29.4
Waterside
heat-exchanger
Welding, stainless steel, plate heat exchanger
Max. Pressure
MPa
1.0
Water system
Water inlet/outlet
pipeline diameter
133mm
Type Fin coil
Air flow volume
*10
3
m
3
/h
108 120 132 144 156 168 180 192
Air side
heat
exchanger
Fan motor input
kW
0.7*9 0.7*10 0.7*11 0.7*12 0.7*13 0.7*14 0.7*15 0.7*16
L mm 2492 2492 2492 2492 2492 2492 2492 2492
W mm 6650 6650 8100 8100 9550 9550 11000 11000
Dimension
(mm)
H mm 1820
30kW master 1620x1034x2041
65kW master 2612x1034x2041
Packaging
dimension
(mm)
65 kw auxiliary 2612x1034x2041
Total weight kg 3240 3500 3940 4200 4640 4900 5340 5600
Optional auxiliary heater kW 67.5 75 82.5 90 97.5 105 112.5 120
