CD 30 ÷ 520
13
3. surrounding Temp. of unit work is shown as follows웛
Name Cooling operation Heating operation
Water-outlet temperature 7°C ÷ 12°C 45°C ÷ 50°C
Air-side heat-exchanger
Air-inlet temperature
17°C ÷ 43°C -10°C ÷ 21°C
6. Sound pressure level
Note: Sound pressure level is measured on each side at 1500mm distance and 1660mm height.
This drawing shows the testing way of single module. When there are some module units combined,
the testing points on the side will be the center on the side of combined unit system.
Air outlet
Center D
Center ACenter B
Center C
