MAXA R407C - Specification

CD 30 ÷ 520
11
5. Specification
CD
Model
30 65 95 130 160 195 225 260
KW 65 95 130 160 195 225 260 240
Cooling
Capacity
*1000 kcal/h 55.9 81.7 111.8 137.6 167.7 193.5 223.6 206.4
KW 69 101 138 170 207 239 276 256
Heating
capacity
*1000 kcal/h 59.34 86.86 118.68 146.2 178.02 205.54 237.36 220.2
Cooling input kW 10 21.5 31.5 43 53 64.5 74.5 86
Heating input kW 9.8 21 30.8 42 51.8 63 72.8 84
Power
380V 3N 50Hz
Control type Wire control
Safety protection device
High/low-pressure switch, anti-frost switch, water-flow switch, over-load
protection, and power phases sequence protection.
30kW master+65kW master+
65 kW auxiliary modules
1+0+0 0+1+0 1+0+1 0+1+1 1+0+2 0+1+2 1+0+3 0+1+3
Compressor input kW 9 18.5 27.5 37 46 55.5 64.5 74
Refrigerant R407C
Refrigerant kg 4.5*2 4.5*4 4.5*6 4.5*8 4.5*10 4.5*12 4.5*14 4.5*16
Water flow volume
m
3
/h
1.45 3.11 4.56 6.62 7.67 9.33 10.78 12.44
Water resistance
loss kPa
29.4
Waterside
heat-exchanger
Welding, stainless steel, plate heat exchanger
Max. Pressure
MPa
1.0
Water system
Water inlet/outlet
pipeline diameter
133mm
Type Fin coil
Air flow volume
*10
3
m
3
/h
12 24 36 48 60 72 84 96
Air side
heat
exchanger
Fan motor input
kW
0.7*1 0.7*2 0.7*3 0.7*4 0.7*5 0.7*6 0.7*7 0.7*8
L mm 1514 2492 2492 2492 2492 2492 2492 2492
W mm 850 2300 3450 4600 5750 6900 8050 9200
Dimension
(mm)
H mm 1820
30kW master 1620x1034x2041
65kW master 2612x1034x2041
Packaging
dimension
(mm)
65 kw auxiliary 2612x1034x2041
Total weight kg 440 700 1140 1400 1840 2100 2540 2800
Optional auxiliary heater kW 7.5 15 22.5 30 37.5 45 52.6 60
