Display now shows C1.2. Press [] and select the decimal point
position for tension. Press and hold [] for two seconds (until
the display starts flashing) to store the decimal point position
chosen.
Display now shows C1.3. Press [] and enter the maximum
tension. Press and hold [] for two seconds (until the display
starts flashing) to store the parameter. This value scales the
output. The output will be at 10 volts or 20 mA when the
measured tension matches this value.
Display now shows C1.4. Press [] and enter the calibration
tension that will be applied to the load cell. Press and hold []
for two seconds (until the display starts flashing) to store the
parameter.
