Tension calibration
errors
Display
Error description
PASS
Calibration was successful. No Errors found.
Er 1
Signal read by the amplifier is too large when maximum tension is
applied. This is caused by maximum tension being too large. Reduce
maximum tension.
Er 2
Signal read by the amplifier is too small. Too little of the load cell range is
being used, thus the gain is greater than 32:1. Use more of the load cell
range or set maximum tension higher.
Er 3
Roller weight too large. Roller weight exceeds 90% of the load cell rating.
Make roller weight smaller.
Er 4
Calibration tension is greater than Maximum tension. Make Maximum
tension larger than Calibration tension.
Er 5
Maximum tension exceeds the load cell rating. Lower wrap angle, make
roll weight smaller or get higher rated load cells.
Table 3. Load cell calibration errors
