Digital input threshold
Parameter #
Description
Default
Range
P.12
Sets the digital input threshold for either 5V or 24V
operation.
When set for 5V, the threshold between on and off
is 2.5 volts with 20% hysteresis.
When set for 24V, the threshold between on and
off is 12 volts with 20% hysteresis.
24 volts
n/a
Calibrate the analog outputs (not normally changed)
CAL0 – These parameters set the offset and gain for the outputs to calibrate the outputs to real
volts or real current. The parameters compensate for component tolerances on each DLCA.
These parameters are calibrated at the factory and are not reset by the power-up function reset
parameters to default.
If these need to be changed connect a volt meter or current meter as appropriate to the output
that is being calibrated.
Parameter #
Description
Range
C0.1
Sets the 0 to 10V output to 0%.
Change the value until the meter reads 0.00 volts
{0, 9999}
C0.2
Sets the 0 to 10V output to 100%.
Change the value until the meter reads 10.00 volts
{0, 9999}
C0.3
Sets the 4 to 20mA output to 0%.
Change the value until the meter reads 0.00 milliamps.
{-999, 9999}
C0.4
Sets the 4 to 20mA output to 100%
Change the value until the meter reads 20.00 milliamps
{0, 9999}
C0.5
Sets the 0 to 1mA output to 0%.
Change the value until the meter reads 0.00 volts or 0.00
milliamps
{0, 9999}
C0.6
Sets the 0 to 1mA output to 100%.
Change the value until the meter reads 10.00 volts or 1.00
milliamps.
{0, 9999}
