Maxent 42" - Connecting a DVD

15
15
EN
Display Connections
Using Composite Input
Connect the Video (yellow) out connector from
the VCR to the Video (yellow) input on the back
of TV.
Connect the red (R) and white (L) audio output
from the VCR to the R and L audio input located
next to the Video (yellow) connector.
Note:
 There are two sets of composite inputs
provided.
 For TV Channels setup please refer to VCR
user manual for details.
Ant. In
Antenna
Connecting a DVD
Using HDMI Input
Connect the HDMI Connector from the DVD to
the HDMI input located on the back of the TV.
HDMI
HDMI Cable
DVD PLAYER
