76
Appendix
76
EN
Specifications for 42” (con’t)
Pin Assignments For D-SUB connector (in / loop out)
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 RED 4 N.C. 7 GREEN Return 10 GND 13 H-SYNC
2 GREEN 5 GND 8 BLUE Return 11 N.C. 14 V-SYNC
3 BLUE 6 RED Return 9 5V Supply 12 DDC Data 15 DDC Clock
Pin Assignments For 19 Pin HDMI connector (digital only)
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 HDMI_RX2+ 9 HDMI_RX0- 17 Ground (For +5V)
2 Ground (For +5V) 10 HDMI_RXC+ 18 IN_5V
3 HDMI_RX2- 11 Ground (For +5V) 19 RX_HOTPLUG
4 HDMI_RX1+- 12 HDMI_RXC-
5 Ground (For +5V) 13 No Connect
6 HDMI_RX1- 14 No Connect
7 HDMI_RX0+ 15 RX5V DDC SCL
8 Ground (For +5V) 16 RX5V DDC SDAt
Y/PB/PR For Component 1
Mode Resolution Refresh Rate
1 720 x 480i 60
2 720 x 480p 60
3 1280 x 720p 60
4 1920 x 1080i 60
Maximum Resolution Up to 1024 x 768
Dimensions & Weight
With/Stand Without/Stand
Width 1072.4 mm/100 1/2” 1072.4 mm/100 1/2”
Height 788.8 mm/31” 748.8 mm/29 1/2”
Depth 260 mm/10 1/4” 94.5 mm/3 3/4”
Weitht 37.5 kgs/82.7 lbs 39.5 kgs/87.1 lbs
Operating
Temperature 0 ~ 40
o
C (32 ~ 104
o
F)
Relative humidity 20 ~ 85%
Altitude 10,000 feet
Non-Operating
Temperature -10 ~ 60
o
C (14 ~ 140
o
F)
Relative humidity 10 ~ 85%
Altitude 10,000 feet
HDMI Signal
Type Digital
Polarity Positive or Negative
Frequency H: support to 31K ~ 64KHz
V: support to 50 ~ 70Hz
Audio Signal Audio: 1.0Vp-p
