Specifications for 50” TV(con’t)
Pin Assignments For D-SUB connector (in / loop out)
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 RED 4 N.C. 7 GREEN Return 10 GND 13 H-SYNC
2 GREEN 5 GND 8 BLUE Return 11 N.C. 14 V-SYNC
3 BLUE 6 RED Return 9 5V Supply 12 DDC Data 15 DDC Clock
Pin Assignments For 19 Pin HDMI connector (digital only)
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 HDMI_RX2+ 9 HDMI_RX0- 17 Ground (For +5V)
2 Ground (For +5V) 10 HDMI_RXC+ 18 IN_5V
3 HDMI_RX2- 11 Ground (For +5V) 19 RX_HOTPLUG
4 HDMI_RX1+- 12 HDMI_RXC-
5 Ground (For +5V) 13 No Connect
6 HDMI_RX1- 14 No Connect
7 HDMI_RX0+ 15 RX5V DDC SCL
8 Ground (For +5V) 16 RX5V DDC SDAt
HDMI Signal
Type Digital
Polarity Positive or Negative
Frequency H: support to 31K ~ 64KHz
V: support to 50 ~ 70Hz
Audio Signal Audio: 1.0Vp-p
Y/PB/PR For Component 1
Mode Resolution Refresh Rate
1 720 x 480i 60
2 720 x 480p 60
3 1280 x 720p 60
4 1920 x 1080i 60
Maximum Resolution Up to 1360 x 768
Dimensions & Weight
With/Stand Without/Stand
Width 1257 mm/49 1/2” 1257 mm/49 1/2”
Height 889 mm/35” 856 mm/33 3/4”
Depth 260 mm/10 1/4” 110 mm/4 1/3”
Weitht 49.9 kgs/110 lbs 48.1 kgs/106 lbs
Operating
Temperature 5 ~ 40
o
C
Relative humidity 20 ~ 70%
Altitude 307~1013 hpa
Non-Operating
Temperature -20 ~ 70
o
C
Relative humidity 5 ~ 85%
Altitude 307~1013 hpa
