Specifications
Technical Data
EPOS4 EtherCAT Card Hardware Reference
CCMC | 2019-11 | rel8613
2-7
2 SPECIFICATIONS
2.1 Technical Data
Table 2-4 Technical data
EPOS4 EtherCAT Card (581245)
Electrical
Rating
Nominal power supply voltage +V
CC
10…70 VDC
Absolute supply voltage +V
min
/ +V
max
8 VDC / 76 VDC
Interface
EtherCAT input
EtherCAT output
As to IEEE 802.3 100 Base T
Max. bit rate 100 Mbit/s (full duplex)
Physical
Weight approx. 7 g
Dimensions (L x W x H) 41 x 25 x 9.2 mm
Mounting Card edge connector, PCIe; 2x18 position
Environment
Temperature
Operation −30…+60 °C
Extended range
(1)
For details consult Hardware Reference of
respective EPOS4 controller
Storage −40…+85 °C
Altitude
(2)
Operation 0…10’000 m MSL
Humidity 5…90% (condensation not permitted)
(1) Operation within the extended range is permitted. However, a respective derating (declination of
output current I
cont
) as to the stated values will apply.
(2) Operating altitude in meters above Mean Sea Level, MSL.
